The BEA Flatscan Set is a twin pack of safety sensors for use on automatic swing doors. The kit contains everything you need to install and also configure the sensors.
The LZR Flatscan SW kit is supplied with two sensor modules, one for installation on each side of the door, near the upper corner of the door leaf. The power cable is 2500mm long, with a master-slave cable at 450mm, which connects the two Flatscan SW units.
With only three steps - 1. Teach-in 2. Smart Senor 3. Environments - these door sensors will learn the door leaf size, detection zone, and direct surroundings, making for easy installation. Flatscan SW uses time-of-flight laser technology that works consistently regardless of floor covering or surroundings such as barriers.
Make sure to check the compatibility of the door controller before you install Flatscan SW sensors, as it requires a dedicated Fieldbus protocol to communicate with the controller.
The Flatscan SW covers the entirety of the door leaf for complete protection, with 70 points divided over 90 degrees as the door opens. Also, these safety sensors cover the hinge area with 100 points divided over 16 degrees in the 'pinch zone'.
Key features:
- Supply voltage: 12V-24V DC with 15% tolerance
- Under 2W power consumption
- 4m diagonal detection range with 2% reflectivity
- Presence detection mode
- IP54 rated
- Temperature range when powered: -30 to +60 degrees C
- Dimensions: 85mm x 142mm x 33mm
- Conforms to DIN 18650 and EN 16005
Included in the set:
- 2 x Flatscan sensor modules
- Mounting bases
- Protective flexible tube for cabling
- Power and master/slave cables
- Clamp and plug
- Installation instructions
