CDVI BO800Rn 2.5 Metre Architectural Handle With 2 X 400Kg Monitored Magnets

• Number of Relays: 1 x NO/NC (per maglock)
• Fail Safe / Fail Secure: Fail safe
• Mounting: Surface, vertical or horizontal Min
• Voltage (V) 12Vdc Max Voltage (V) 24Vdc
• Voltage AC/DC: DC
• Max Power Consumption (mA) 480 @ 12Vdc / 240 @24Vdc

Features

• Architectural pull handle with 2 x 400kg monitored magnets
• Fit to new doors or retrofit to existing doors
• Ideal for high traffic sites that need high holding force and an aesthetic finish
• Can be cut down to bespoke size and sprayed in custom RAL colour
• Suitable for wooden, metal, or glass doors
• Optional mimic handle section for reverse side of door - for a neater finish

Dimensions

• Product Height (mm) 2500
• Product Width (mm) 136
• Product Depth (mm) 68
• Product Weight (kg) 13

DATASHEET

BO800RN
