CDVI BO800Rn3M 3 Metre Architectural Handle With 2 X 400Kg Monitored Magnets
The Bo800Rn-3M By Cdvi Is A 3M Architectural Handle With 2 X 400Kg Monitored Magnets That Can Be Fitted To Either New Or Existing Doors
£538.00 exc VAT
- Number of Relays: 1 x NO/NC (per maglock)
- Fail Safe / Fail Secure: Fail safe
- Mounting: Surface, vertical or horizontal Min
- Voltage (V) 12Vdc Max Voltage (V) 24Vdc
- Voltage AC/DC: DC Max Power Consumption (mA) 480 @ 12Vdc, 240 @ 24Vdc
Features
- Architectural 3-metre pull handle with 2 x 400kg monitored magnets
- Fit to new doors or retrofit to existing doors
- Ideal for high traffic sites that need high holding force and an aesthetic finish
- Can be cut down to bespoke size and sprayed in custom RAL colour
- Suitable for wooden, metal, or glass doors
- Optional mimic handle section for reverse side of door - for a neater finish
Dimensions
- Product Height (mm) 3000
- Product Width (mm) 136
- Product Depth (mm) 68
- Product Weight (kg) 17
DATASHEET
