RGL 1203Sm-2 Enerflex 12V 3Amp Power Supply – Large Box

• Full current to load
• 12-14VDC adjustable voltage output
• Additional battery charging
• Deep discharge protection
• Current limiting
• Short circuit protection
• 230V fused input
• Mains transient protection
• Compliant to EMC EN61000-6-1 & 3
• Up to 92% energy efficiency (reduced running costs and lower power usage)

Features

• Switchmode technology
• DIN Rail design for greater versatility
• Mild steel construction
• White powder coated
• LED Indicators (mains, batt, output)
• Separate fused main connectors
• Full electronic protection
• Onboard tamper protection
• Converts power more efficiently
• Multiple cable entry
• Allows for 1 x 7/9aH batteries (SM-1)
• Utilising market leading Gallium Nitride
  technology (GaN)

Dimensions

310H x 340W x 80D (mm)
3.07Kg Boxed 2.84Kg Unboxed

Contents

Power Supply Unit
2 x Battery Leads (1 x Red, 1 x Black)
1 x Earth Lead - Connected
Wiring instructions included

DATASHEET

1203SM-2
